Especificaciones:
Modelo
| XH430-W210-T
|
Peso (g)
| 82g
|
Dimensiones (mm)
| 28.5mm x 46.5mm x 34mm
|
Ratio de reducción
| 212.6 : 1
|
Tensión de operación (V)
| 11.1
| 12
| 14.8
|
Par de parada (N.m)
| 2.2
| 2.5
| 3.1
|
Par motor (A)
| 1.2
| 1.3
| 1.5
|
Velocidad sin carga (RPM)
| 46
| 50
| 62
|
|
MCU
| ST CORTEX-M3 ( STM32F103C8 @ 72MHZ,32BIT)
|
Posición del sensor
| Contactless absolute encoder (12BIT,360°) by AMS
|
Motor
| Maxon Motor
|
Resolución
| 0.088° x 4,096 steps
|
Rango operativo
| Current Control Mode : Endless turn Velocity Control Mode : Endless turn Position Control Mode : 360 Extended Control Mode : ±256 Current-based Position Control Mode : ±256 PWM Control Mode : Endless turn
|
Tensión de entrada (V)
| 10~14.8V (Recommended voltage : 12V)
|
Temperatura de trabajo (°C)
| -5°C ~ 80°C
|
Señal de comandos
| Paquete digital
|
Tipo de Protocolo
| Half duplex Asynchronous Serial Communication (8bit,1stop, No Parity)
|
Conexión física
| TTL Level Multi Drop Bus
|
ID
| 253 ID (0~252)
|
Velocidad de comunicación
| 9600 bps ~ 4.5 Mbps
|
Feedback
| Posición, velocidad, Carga, Trayectoria, Temperatura, voltaje de salida, etc
|
Material
| Carcasa : Metálica(Frontal y en el medio) Engineering Plastic (detrás) Engranajes: metálicos
|
Standby current (mA)
| 40 mA
|
Más información aquí:
http://emanual.robotis.com/docs/en/dxl/x/xh430-w210/
